Panasonic UR1865ZM2 2500mAh 3C 18650 Battery

Panasonic UR1865ZM2 2500mAh 3C 18650 Battery

INQUIRY

Panasonic UR1865ZM2 2500mah 3C Battery

>100K in stock, Panasonic ZM2 New cells, contact us to get a special offer.
Fast shipping by air or ocean in original packing.
We hold Datasheet MSDS UN38.3 UL CB IEC62133 SGS PSE BIS and Test Reports.

Panasonic ZM2 Cell Specification

Minimum capacity: 2470 mAh
Nominal Capacity: 2550 mAh
Nominal voltage: 3.6V
Max. Continuous discharge current: 3C, 7.5A
Charging voltage 4.20V
Plus pool: Flat Top
Chemistry: LiNiMnCoO2
Diameter: 18.35mm ± 0.15mm
Height: 65 mm ± 0.2 mm
Weight: 46.6g ± 1.2g

Made in China

Panasonic Cylindrical Battery Cells:

Type	Voltage (V)	Nominal capacity	Max. cont. current	Dimensions (mm)	Construction
UR18650RX	3,6V	2000mAh	20A	ø 18,5×65,3	Cylindrical
UR18650AY	3,6V	2150mAh	4,3A	ø 18,3×64,9	Cylindrical
UR18650AA	3,6V	2150mAh	5A	ø 18,3×65,1	Cylindrical
UR1865ZM2	3,6V	2550mAh	7.5A	ø 18,3×65,3	Cylindrical
NCR18500A	3,6V	2040mAh	4A	ø 18,5×49,5	Cylindrical
NCR18650BD	3,6V	3030mAh	10A	ø 18,5×65,3	Cylindrical
NCR18650BF	3,6V	3250mAh	4,87A	ø 18,5×65,3	Cylindrical
NCR18650GA	3,6V	3350mAh	8A	ø 18,5×65,3	Cylindrical
